beiben tractor unit

BEIBEN TRACTOR UNIT

BEIBEN TRACTOR UNIT, is the only brand in China who is operating under the license of Germany Benz Heavy-Duty Truck technology. And BEIBEN can also match with Germany Benz, Deutz Engine and domestic Weichai, Yuchai Engine and cover types from 240HP to 48HP. The products are widely used in railways, chemicals, electricity and water, fire fighting, bank and so on.

FREE QUOTE NOW

TOP Features

  • Cooperation with Benz.
  • Meet the European ECER29 safety regulations and possess security of same level of European automobiles.
  • Cooperation with the first-class international design houses: The type V3HT takes ACTROS of Benz as technology standard.

Gallery

The BEIBEN tractor unit is composed of about four types: V3 series, V3M series, V3HT series and NG80 series. Among the four types, the V3 series and NG80 series are more universal.

V3 series

Dimension(mm) Long 9930
  Wide 2500
  High 3630
Wheel base(mm) 4800
Drive 4×2
Engine Model WP10.420E32
Cabin V3/ Long cab,flat roof
Clutch(mm) Φ430
Front Axle 7.5T
Rear/Mid Axle Model/speed radio Double Reduction Driving Axle /5.263
Steering System ZF8098
Braking System Dual Circulation Air Brake System
Fuel Tank(L) 400L
Frame/mm 317×70×8.5+7
Tire 315/80R22.5
Front/Rear Overhang 1410/3230
Transmission Fuller 16JS200T
Curb Weight(kg) 8600
Up Body Volume(m³) 12
Max Speed(km/h) 100

NG80 series

Overall dimension (mm) 6295x2500x3260
Driving Model 4x2
Wheel base (mm) 3800
Curb weight (kg) 9300
Gross towing trailer weight (kg) 1800
Engine Model WD615.46 , WEICHAI brand, Power: 360hp
Gearbox Model 12JS200T, mechanical type,Based on Fuller Eaton technology ,12Forward speed gear
Frame Based on Germany Benz Technology
Axle(Front, Middle and Rear) Based on Mercedes Benz Technology
Brake system Safe(consist of Service brake, Assistant brake and Park brake)
Steering system Model ZF8098
Fuel tanker capacity (L) 400
Clutch Model 430,Hydraulic boosting
Tire 12.00R24 radial tire
Electrical system 2 Batteries (12V/135Ah each )
Safe Cab(driver die Zero record) full steel skeleton structure, covered with double layer steel plate;
Fifth wheel 90 JOST brand
Dimension for Upper body /

  • Wide-range in application: BEIBEN tractor can connect with different semi trailer trucks such as tank truck, cargo truck, dump truck and crane truck for more use.
  • Anti-skidding: BEIBEN tractor unit can prevent the idling conditions of the drive wheels during the vehicle driving on the slippery road. And as to starting and accelerating the vehicle, the tractor can also ensure more stationarity, especially in the snow or muddy road.
  • Flexibility: Make the vehicle has a better flexibility when towing a vehicle.
  • Reliable operation: Ensure the reliable connection, easily and quickly handle between tractor units and semi trailer trucks.
  • stationarity: The traction can be passed to the semi trailers smoothly and produce cushioning effect.

Before driving, please check the following items every day:

  • Emergency supplies, such as extinguisher.Before starting the engine, please check the following items.
  • Fuel capacity
  • Locking mechanism in cab.
  • The vehicle's lighting, steering, and brake lights.
  • Engine oil
  • Tire pressure
  • Fuel prefilter, After starting the engine, please check the following items
  • Indicator light of oil pressure
  • Steering wheel free play
  • Brake air pressure

As the top-class manufacturer of trucks, BEIBEN is well known for the “Top of the Line” and owns many different kinds of quality certification: CE Certification; ISO9001-2008 Certification; TÜV Certification; BV (Bureau Veritas) Certification; SGS Certification, etc.
